Waste oil heater with CH and HW, 39-55kW

Waste oil heater with CH and HW, 39-55kW

Product code: HP-145-WH

Brand: Hiton

Modern recycling of superfluous vegetable, mineral and synthetic oils. Power 39-55kW. For supplementing or wholly replacing heating, connection possible to central heating system and hot water system. Overheating and fuel overflow protection
🔴 Out of stock
Gross price: 3.369,97 €
Waste oil heater with CH and HW, 39-55kW
Waste oil heater with CH and HW, 39-55kW
Fáradtolaj kályha, 30-42kW ÚJ
Fáradtolaj kályha, 30-42kW ÚJ
Waste oil heater with CH and HW, 39-55kW
Waste oil heater with CH and HW, 39-55kW
Waste oil heater with CH and HW, 39-55kW
Waste oil heater with CH and HW, 39-55kW
Waste oil heater with CH and HW, 39-55kW
Waste oil heater with CH and HW, 39-55kW

Product description

Description

Suitable uses:

  • Heating equipment
  • It can be connect to the hot water system and central heating system
  • Easy handling
  • Modern recycling of superfluous vegetable, animal, synthetic and mineral oils and fats
  • The furnace does not need to be dissembled when changing the fuel, only the settings need to be adjusted
  • LED display
  • Manual ignition
  • Oil overflow and ignition protection
  • Built-in overheat protection checking system

Suitable for burning following oils:

  • Vegetable oils (bio-fuel)
  • Used vegetable oils (including catering industry)
  • Fuel-containing bio-canola oil
  • Mineral oils
  • Used mineral oils (engine-, transmission-, hydraulics and HBO I, II, III fluids)
  • Synthetic oils

Technical details

  • Fuel: waste oil, fuel and other burnable oils
  • Container: 55l
  • Power: 39-55kW
  • Coil power: 6-8kW
  • Oil consumption: 3.13-4.38kg/h
  • Heating capacity: 2660m3
  • Cold and hot water feed pipe diameter: GW-1/2"
  • Voltage: 230V/50Hz
  • Current (fuse): 1.6A
  • Chimney needed (d): 150mm
  • Weight: 117kg

Product packing

Pack number Dimensions Weight
1 120 x 70 x 150 cm 125 kg

Delivery fee

Delivery method Gross price
Pickup in Nagytarcsa 0,00 €
Pickup in Debrecen 0,00 €

Downloads

User Manual HU
