MMA/TIG Superior 320 welding machine CE, VRD, 230-400V
Product code: 816036
Brand: Telwin
Product description
Main features
- Direct current (DC) MMA and TIG (scratch start) electrode inverter welding machine, 270A, with digital display. Dual voltage.
- Designed for welding cellulose electrodes. Arc-force adjustment and hot start according to the type of electrode used. Anti-stick protection
- Usable electrodes: cellulose and coated aluminium, rutile, basic, stainless steel and cast iron electrodes up to a Ø of 6 mm.
- High stability of the welding current in power supply voltage variations. Thermostatic, overvoltage, undervoltage, overcurrent protection. Compatible for use with the motor generator (230V, +/-15%).
- Instantaneous control of welding drop transfer. With VRD (Voltage Reduction Device).
- Compact and easy to transport. Set up for remote control.
Specifications
| Three phase mains voltage: 230/400V | Mains frequency: 50/60Hz |
| Current Range: 10-250/10-270A | Max Current (40 °C): 220@42%/270 @ 35%A |
| Max. no load voltage: 60/63V | DC Current: 185/205A |
| Max. absorbed current: 19 / 14,4A | Max. absorbed power: 7/9kW |
| Absorbed power at 60%: 6-6,5kW | Absorbed current at 60%: 15/10A |
| Efficiency: 87% | Usable electrodes in DC: 1,6-6mm |
| Power factor: 0,8 | Protection degree: IP23 |
| Weight: 10,2kg | Dimensions: 47 x 19 x 35cm |
Product packing
| Pack number | Dimensions | Weight |
|---|---|---|
| 1 | 50.5 x 21.5 x 40 cm | 11 kg |
Delivery fee
| Delivery method | Gross price |
|---|---|
| Pickup in Nagytarcsa | 0,00 € |
| Pickup in Debrecen | 0,00 € |
| DHL Worldwide Express | 152,30 € |
